Features & Performance

nSMT type, 67Pin.

nModule card thickness: 0.8+/-0.08mm.

nSingle ended signaling, impedance:  85Ω

nData rate: 16GT/s +.

nTooling type:  :KEY B， KEY E，KEY M

Product Specifications

Product Catalog

Product Drawings

NGFF 2.65H KEY B GEN4 0.5A

5621D3-040HX111R_NGFF 2.65H KEY B GEN4 0.5A_Rev A.PDF

NGFF 2.65H KEY E GEN4 0.5A

5621D3-040HX411R_NGFF 2.65H KEY E GEN4 0.5A_Rev A.PDF

NGFF 2.65H KEY M GEN4 0.5A

5621D3-040HXB11R_NGFF 2.65H KEY M GEN4 0.5A_Rev A.PDF

Find more detail please contact  : connsales@deren.com
